| Feature |
Specification/Options |
| Safe working load (SWL) under the spreader |
Single 41t,45t,50t /Twin 50t/60t*/65t* |
| Gantry span |
Up to 10wide |
| Hoisting height |
Up to 1 over 7 |
| Wheelbase |
6.4m I 6.9m I 9.6m |
| No of wheels and tyre sizes |
8 wheels (18.00-25 40PR / 21.00-25 40PR) 16 wheels (16.00-25 32PR} |
| Main power supply |
Classic RTG: Diesel engine generator (Constant Speed or Variable Speed Generator [VSG]) E-RTG: Cable reel or Busbar Hybrid RTG: Battery system plus VSG engine |
| Rope reeving |
4 rope reeving with Electronic Antisway system / Electro-Mechanical antisway system/ Maxstable rope reeving system |
| Control system integrator |
GENMA |
| Trim (optional} |
±5° (Electric) |
| Micro motions (Gantry longitudinal / Trolley transverse / Skew |
±300mm I ±200mm I ±4.5° (Electric) |
| Hoisting with SWL under spreader |
20 I 26 I 30 m/min
0.067 I 0.217 I 0.217 m/s2 |
| Hoisting with empty spreader |
58 I 52 I 60 m/min
0.193 / 0.217 / 0.217 m/s2 |
| Trolley travel |
70 m/min
0.292 m/s2 |
| Gantry travel |
130 m/min
0.271 I 0.361 m/s2 |
