| Model |
|
F500.RS2 |
| Attachment type |
|
20â/40â² Top Pick Spreader |
| Load capacity on tires at 1st/2nd/3rd row (no stab) |
kg |
46.000 | 31.000 | 16.000 |
| Load centre distance at 1st/2nd/3rd row |
mm |
1.780 | 3.850 | 6.400 |
| Load capacity on stabilizers at 1st/2nd/3rd row * |
kg |
Stabilizers not available |
| Load centre to front face of the truck |
mm |
830 |
| Lifting height under twist-lock |
mm |
16.100 |
| Stacking Ability â containers |
|
1 over 5 = 6 x 8â6â |
| Wheelbase |
mm |
6.500 |
| Service weight â unladen |
kg |
71.000 |
| EU Stage 3a Engine make&model (Rated Power) |
(kw) |
CUMMINS QSM11 (250) |
| EU Stage 4 Engine make&model (Rated Power) |
(kw) |
SCANIA DC13 (257) |
| Transmission make&model |
|
DANA TE32 |
| Service Brakes |
|
Wet Disk on front wheels |
| Tires size |
|
18.00-25 |
| Overall width â excluding Spreader |
mm |
4.185 |
| Overall length â including spreader |
mm |
12.000 |
| Overall height |
mm |
4.800 |
| Seat height |
mm |
2.720 |
| Spreader rotation â clockwise/anticlockwise |
deg |
-105 / +195 |
| Spreader side-shift â left / right |
mm |
+800 / -800 |
| Boom Angle (min / max) |
deg |
0 /60 |
