| Feature |
Specification/Options |
| Safe working load (SWL) under the spreader |
Single 41t /Twin 50t*/Twin 60t*/Twin 65t* |
| Trolley arrangement |
Rotating / Low-profile fixed |
| Gantry rail span |
20-55m |
| Cantilever outreach |
Up to 18m |
| Hoisting height |
Up to 1 over 6 |
| Rope reeving |
Maxstable rope reeving system |
| Clearance between legs |
15m (with low-profile fixed trolley)/ 17m / 18m
49ft / 55ft / 59ft |
| Overall length (buffer to buffer) |
25.3m(with low-profile fixed trolley)/ 26.19m - 28.19m 83ft I 86ft - 92ft 6in |
| Main power supply |
50 or 60Hz, 3-phase, 4-wire, voltage as required |
| Power supply method |
Cable reel / busbar* |
| Cabin |
GENMA OEM / Brieda / Merford (The cabin rotates with the trolley) |
| Trim |
±5° (Electric) |
| Micro motions (headblock) (Gantry longitudinal / Trolley transverse / Skew) |
±250mm I ±250mm I 5°(electric / hydraulic) ±10in / ±10in / 5° |
| Hoisting with SWL under spreader |
40 I 70 I 80/ 90m/min 131 / 229 / 261/ 295ft/min 0.50m/s2 |
| Trolley travel |
60 / 100 I 120 / 150m/min 197 / 328 / 394 / 492 ft/min
0.40 - 0.50 m/s2 |
| Gantry travel |
120 / 150m/min 4.5 I 5.5mph
0.30 - 0.40 m/s2 |
| Trolley rotation |
2rpm |
