| Model |
|
FH45.4 |
| Attachment type |
|
20â/40â² Top Pick Spreader |
| Attachment mounting |
|
on inverted forks |
| Capacity on tires |
kg |
35.000 |
| Load centre distance (+/- out/in rach) |
mm |
1.300 (+/- 100) |
| Load centre to centre of front axle |
mm |
2.480 |
| Lifting height under twist-lock |
mm |
9.000 |
| Stacking Ability â containers |
|
1 over 3 = 4 x 9â6â |
| Wheelbase |
mm |
5.750 |
| Service weight â unladen |
kg |
68.800 |
| EU Stage 3a Engine make&model (Rated Power) |
(kW) |
CUMMINS QSM11 (250) |
| EU Stage 4 Engine make&model (Rated Power) |
(kW) |
SCANIA DC13 (257) |
| Transmission make&model |
|
DANA TE32 |
| Service Brakes |
|
Wet Disk on front wheels |
| Tires size |
|
18.00-25 |
| Overall width |
mm |
4.185 |
| Overall length (including spreader) |
mm |
10.785 |
| Overall height (mast lowered) |
mm |
8.650 |
| Seat height |
mm |
2.400 |
| Mast tilt |
deg |
3 / 5 |
| Spreader side-shift |
mm |
+400 / -400 |
| Spreader hydraulic (mechanic) pile slope |
deg |
2 / 2 |
