| Feature |
Specification/Options |
| Safe working load (SWL) under the spreader |
Single 41t /Twin 50t*/Twin 60t*/Twin 65t* |
| Gantry rail span |
Up to 11 wide |
| Hoisting height |
Up to 1 over 6 |
| Rope reeving |
Maxstable rope reeving system |
| Overall length (buffer to buffer) |
14.5m |
| Main power supply |
50 or 60Hz, 3-phase, 4-wire, voltage as required |
| Power supply method |
Cable reel |
| Trim |
±5° (Electric) |
| Micro motions (headblock) (Gantry longitudinal / Trolley transverse / Skew) |
±250mm I ±250mm I 5°(electric / hydraulic) ±10in / ±10in / 5° |
| Hoisting with SWL under spreader |
35 I 40 I 45m/min 114 /131/ 147ft/min
0.35 m/s2 |
| Hoisting with empty spreader |
70 /80/ 90m/min 229 /262/ 295ft/min
0.50m/s2 |
| Trolley travel |
60 / 72m/min 197 / 236ft/min
0.30m/s? |
| Gantry travel |
240 1270 I 300m/min 9 / 10 / 11mhp
0.40m/s2 |
